Zinc Plated Metal Mesh Containers Anti Dust Rigid Mesh Pallet Cages

Basic Information
Place of Origin: China
Brand Name: Wuhao
Model Number: Customized
Minimum Order Quantity: 50 units
Price: Negotiatable
Packaging Details: (1) Stretch films and plastic banding wrapped (2) Packaged as per customer's requirements
Delivery Time: 15-20 days
Payment Terms: T/T
Supply Ability: 40000 per month
Detail Information
Product Name: Wire Container Material: Steel
PP Sheet: Yes Surface Treatment: Zinc Plated/ Hot Dip Galvanized/ Powder Coating
Delivery Time: 15-20 Days Certificate: CE
High Light:

metal mesh cage


wire mesh pallet cages

Product Description

PP Sheet Durable Collapsible Wire Container Industrial Folding Cage Zinc Plated
Steel wire mesh container


Steel wire mesh containers is also named foldable mesh bins, boxes or wire containers. This product is made of welded mild steel wire and tubes. Wire mesh side panels fixed with welded U-shaped stiffener or tubular structure at bottom for strengthening. With or without lids. Solid pp sheets can be placed inside the panels to protect fragile goods or easily-scratched-surface goods. This wire cage container can be designed with open gates/doors or fold down sides for easy stacking and collapsing during transport and storage, also for easy access of truck lifts from all sides. With the use of lift truck or forklifts, this wiremesh container can be easily used in logistic steps, such as transportation, loading and unloading, and warehouse storage. The steel mesh containers can be divided into light type and heavy load containers according to capacity.




Item No. Size Folded Self-weight Load Capacity Stackability Load Quantity
External size(MM) Internal size(MM) (MM) (kg)±2% (kg) layers 40 HC
H-1 1600*1150*1075 1525*1070*830 1600*1150*360 125 1500 3 112
H-2 1150*800*730 1080*720*500 1150*800*360 70 1000 4 224
H-3 1370*900*920 1300*820*680 1370*900*360 107 1000 4 168
H-4 1950*1150*1300 1875*1070*1030 1950*1150*360 190 1500 4 80
H-5 1200*1000*930 1120*920*700 1200*1000*370 110 1200 3 168
H-6 1600*1200*930 1525*1120*710 1600*1200*370 156 1500 3 72
H-7 1412*1140*1200 1315*1095*1035 1412*1140*330 110 1000 3 128
H-8 1170*1000*760 1100*910*580 1170*1000*320 77 1000 4 168




a. Welded wire firm structure

b. Electro galvanized finish or Powder coated finish is available

c. Stackable, collapsible, folds flat to save space

d. Drop gate for easy access when stacked

e. Easy forklift access from all sides

f.  Lowest maintenance cost

g. Other standard options include casters, security lids, shelves, dividers, and card holders are available

h. Product can be customized specification or OEM.

How to get a quick quote?


Specified information would be helpful:

  • External size
  • Internal size
  • Wire Diameter
  • Mesh Size
  • Loading capacity
  • Channel size
  • Weight of container
  • Maximum stacking layers
  • PP/PVC sheets within the container
  • Other fittings requirements.

About Wuhao Company
Wuhao Warehouse Equipment (China) Co. Ltd. , set up in 2007 and focus on manufacturing wire container, wire storage cage, we well cooperated with many other trade companies since 2007.
In 2010 year, we joint stock a factory for new project plastic injection products, such as plastic pallet, plastic circulating box, etc.
These warehouse equipments, wire storage container, plastic pallet, plastic box, being important facilities for various products’ handling, storage, transport. The wire storage containers are widely applied to the industries of hardware, machinery, electronics, tiered warehouse, material logistics, etc., and the plastic pallet, circulating box, are widely applied to the fields of food, aquatic products, chemicals, clothing, pharmaceuticals, tobacco, docks, warehouse logistics, etc.
